Measuring networks the way customers experience them.

x-fabric builds distributed measurement systems for telecom and service providers. Thousands of mosprobes sit on real lines and behave like customers, placing calls, transferring data and watching TV around the clock and reporting what a customer would experience.

Test schedule Illustration
TimeTestPathResult
16:24VoiceSIP to POTSMOS 4.3
16:24DataHTTP downloadOK
16:25IPTVMulticastOn air
16:25DataIPv6 downloadOK
16:26VoiceISDN to SIPMOS 4.1

1Our mission

Measuring what customers experience, not what the network reports.

A person leaning on a white table looks at a large egg whose shell is breaking open at the bottom
Make everything as simple as possible, but not simpler.after Albert Einstein
Connected like an end customer
At the network termination point, mosprobes experience the service as your customers do.
All in-house
We build the hardware, firmware, backend and interface to work together.
Endurance
Systems that measure for years without a break. 24×7
Swiss engineering
Designed and produced in Switzerland.
How mosprobes measure at the network termination point.

2At the network termination point

mosprobes are end customers.

The mosprobe® platform is a distributed test and monitoring system for telecom and service providers, in service since 2006.

mosprobe-ng: aluminium housing with a black front panel and the window of the OLED status display
Front panel with OLED status display

mosprobe-ng

The compact mosprobe.

Housing
Aluminium, milled from solid
Footprint
160 × 100 mm
Cooling
Passive
Power draw
About 6 W
Supply
12 V, 2 A, external
Network
2 × Gigabit Ethernet, 1 × management
Telephony
SIP/RTP*, POTS, ISDN
Also
2 × USB-A, aux, reset button
Display
OLED, with a silent mode for use at customer premises

* Option

Designed and produced in Switzerland.

mosprobe-ng rear panel with Ethernet and telephony ports
mosprobe-ng, rear panel: ports from left to right
  1. Gigabit Ethernet
  2. Gigabit Ethernet
  3. Management
  4. 2 × USB-A
  5. POTS
  6. ISDN
  7. Aux
  8. Reset
  9. Power 12 V, 2 A
mosprobe-ng housing, milled from solid aluminium
Housing, milled from solid aluminium
mosprobe-ng circuit board
Circuit board, our own design

What mosprobe measures

Customers still judge you by voice quality, and they expect the bandwidth you advertise. End-to-end measurements show the voice quality and bandwidth customers receive.

Voice quality
End-to-end calls across SIP/RTP, ISDN and analogue lines, in both directions. Speech quality as MOS with POLQA® (ITU-T P.863), including wideband speech, or with PESQ® (ITU-T P.862) for continuity with existing measurement series; plus call setup, call success, delay, packet loss and jitter.Speech quality, explained
Data and web
HTTP and FTP uploads and downloads at up to gigabit speed, over IPv4 and IPv6. Throughput, responsiveness, reliability and TCP behaviour.Web and data performance, explained
IPTV and more
Multicast channel reception and availability, and custom test cases built on request.IPTV quality, explained
One mosprobe shows the performance of one line. Thousands under central control show performance across the whole network.

3Across the network

One platform for the network termination point, edge and core.

The same platform measures across the whole network, from the end customer's network termination point through the edge to interconnection points in the core, under central control.

  1. Customer

    mosprobe-ng: voice and 1 Gbit/s data
    Pico: 2.5 Gbit/s data

  2. Edge

    10 Gbit/s

  3. Core

    100 Gbit/s

Coast Guard

IP benchmarking at national scale.

Coast Guard uses test heads ranging from units with 100 Gbit/s ports at interconnection points to units at the end customer, synchronised by GPS or PTP (IEEE 1588), for benchmarking to RFC 2544, ITU-T Y.1564, RFC 3393 and RFC 6349. A central controller schedules hundreds of thousands of jobs a day.

Coast Guard in detail

Built for 24×7

Scale
The system scales from a handful of mosprobes to thousands. At scale, it makes over a million measurements per day.
Continuous operation
Central servers with hot standby, and SLA tracking across years.
Open
Web interface, standardised exports, and interfaces to your reporting and alarm systems.
Secure
Encrypted, authenticated control, and individual access rights for every user.
Why it all fits together.

4About us

x-fabric develops test and measurement systems for network operators and service providers, and advises them on quality assurance.

The company was founded in Berlin and is now based in Switzerland. We build the mosprobe-ng's circuit boards and other hardware, its firmware, and the server infrastructure and reporting as one system. Each part is tuned to the others, avoiding gaps and unnecessary overhead. Our customers are large telecom operators and service providers.

Managing director: Roman Puls

Talk to us.
The x of the x-fabric logo as a large grey block, with two climbers on ropes
People who put their all into it. Since 2006.
